07013180

Perle 07013180
See any errors on this page?
Please let us know.

Perle IDS-305G-CSS120D - Industrial Managed 5 port Ethernet Switch w/(4) 10/100/1000BTX RJ45 ports & (1) 1000BBX 1550nm TX / 1310nm RX single-strand single mode simplex (BIDI) SC connector [120km/74.6 miles] (PRO software feature set)
MSRP: $3,385.00
ESP Price: $2,640.00
Contact us for Partner Pricing. (more info)


Free Shipping
Availability: Usually Ships in 24 Hours; However, Due To Shortages Contact Sales to Verify
Product Code: 07013180

Description Technical Specs Drivers & Downloads

The IDS-305G is a 5 port Managed Ethernet Switch that can operate in industrial environments providing advanced performance and enabling real-time deterministic network operation. Four 10/100/1000-Base-T Ethernet ports are available for networking Gigabit and Fast Ethernet devices. One 1000Base-X fiber connection is available to extend Gigabit Ethernet operating distances over fiber.

In addition to extending links over greater distances, utilizing fiber is critical in environments where high levels of electromagnetic interference ( EMI ) is a common phenomenon, like industrial plants. This interference can cause data corruption over copper-based Ethernet links. However, data transmitted over fiber optic cable is completely immune to this type of noise ensuring optimal data transmission across the plant floor.

Perle Industrial-grade Ethernet Switches are designed to stand up to extreme temperatures, surges, vibrations, and shocks found in industrial automation, government, military, oil and gas, mining and outdoor applications.

With over 30 models, the Perle IDS-305G offers a choice of connectors, fiber types, temperature support and operating distances.

Perle’s Fast Setup feature provides simple Plug and Play installation to get your Ethernet devices networked immediately. The familiar Command Line Interface ( CLI ), via in-band Telnet or the out-band serial console port, will be appreciated by CCNA ( Cisco Certified Network Associate ) and CCNP ( Cisco Certified Network Professional ) trained engineers.

The PRO feature set in the IDS-305G is ideal for advanced environments where additional extensive security and network integration functionality is required.

  • AAA ( Authentication, Authorization, Accounting )security protocols: RADIUS and TACACS+
  • SSH, SNMPv3, Telnet and HTTPS secure management sessions
  • Management Access Lists (ACL) by IP address and IP Port number
  • Enforce Password Strength requirements
  • IEEE 802.1x Authentication and Port Security for protection of user access ports
  • Optimize the performance and intelligence of the network with Advanced Protocols: LLDP, GVRP, Voice VLANs, MSTP, GMRP, IPv4 IGMP Snooping and IPv6 MLD Snooping
  • P-Ring, management VLAN, QoS, RMON, N:1 port mirroring and local alert log, are only a few of the comprehensive management functions supported in the IDS-409. In addition, the switch can be managed with an IPv6 address.

The IDS-305G, which comes in a variety of models, are rugged fan-less switches that are hardened to provide superior reliability in -10 to 60°C, or harsh extended operating temperatures from -40 to 75°C. Every component on every industrial (XT) model has been designed and tested to handle operating temperatures between -40 and 75C.

All Perle Industrial Ethernet Switches have a corrosion resistance aluminum case and dual redundant power input with reverse polarity and overload protection. In addition, all units only use high-end components from the leading chip manufacturers to ensure the highest level of durability and reliability.
Features
  • 4 port 10/100/1000Base-T ( RJ45 ) for Gigabit and Fast Ethernet devices
  • 1 port 1000Base-X SC/ST fiber connection
  • PRO feature set including advanced switching, encryption and IEEE 1588 PTP
  • IP Manageability, VLAN and resiliency management
  • Compact, corrosion resistant case attaches to a standard DIN Rail
  • Redundant dual power input 12/24/48 VDC
  • Out-of-band management via RJ45
  • Programmable Controller safety and Hazardous Location Certification
  • -40 to 75C industrial operating temperature ( XT Models )
