Instant Plug & Play
The UPort™ 1150/1150I USB-to-serial converters allow you to connect 1 RS-232/422/485 device to your laptop or workstation through the USB (Universal Serial Bus) port. These plug & play USB solutions are compatible with both new and legacy RS-232/422/485 devices, and are perfect for mobile, instrumentation, and point-of sale applications.
Simplified, Hassle-free Serial Port Expansion
USB plug & play makes serial port expansion easy, and does not require IRQ, DMA, or I/O address resources. Users no longer need to open the chassis or power down the system to add COM ports, saving on setup time and cost.
|
USB Interface
|
|
Compliance
|
USB 1.0/1.1 compliant, USB 2.0 compatible
|
|
Connector
|
USB type A
|
|
Speed
|
12 Mbps (Full-Speed USB)
|
|
• Serial Interface
|
|
Number of Ports
|
1
|
|
Serial Standards
|
UPort 1110: RS-232
UPort 1130/1130I: RS-422/485
UPort 1150: RS-232/422/485
|
|
Connector
|
DB9 male
|
|
• Serial Line Protection
|
|
ESD Protection
|
15 KV embedded
|
|
Optical Isolation
|
2 KV (UPort 1130I only)
|
|
• Performance
|
|
Baudrate
|
50 bps to 921.6 Kbps
|
|
• Serial Communication Parameters
|
|
Data Bits
|
5, 6, 7, 8
|
|
Stop Bits
|
1, 1.5, 2
|
|
Parity
|
None, Even, Odd, Space, Mark
|
|
Flow Control
|
RTS/CTS, XON/XOFF
|
|
FIFO
|
64 bytes
|
|
• Serial Signals
|
|
RS-232
|
TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
|
|
RS-422
|
TxD+(B), TxD-(A), RxD+(B), RxD-(A), GND
|
|
RS-485-4w
|
TxD+(B), TxD-(A), RxD+(B), RxD-(A), GND
|
|
RS-485-2w
|
Data+(B), Data-(A), GND
|
|
RS-485 Data Direction
|
ADDC® (Automatic Data Direction Control)
|
|
• Driver Support
|
|
Operating Systems
|
Windows 9X/ME/2000, Windows XP/2003/Vista/2008/7 x86/x64, WinCE 5.0/6.0, Linux 2.4.x, 2.6.x, 3.0.x
|
|
Note
|
Please refer to Moxa's website for the latest driver support information.
|
|
• Physical Characteristics
|
|
Housing
|
ABS + PC
|
|
Weight
|
Product only: 65 g (0.14 lb)
Packaged: 200 g (0.44 lb)
|
|
Dimensions
|
38.4 x 60 x 20 mm (1.51 x 2.36 x 0.79 in)
|
|
• Environmental Limits
|
|
Operating Temperature
|
0 to 55°C (32 to 131°F)
|
|
Storage Temperature
|
-20 to 70°C (-4 to 158°F)
|
|
Ambient Relative Humidity
|
5 to 95% (non-condensing)
|
|
• Standards and Certifications
|
|
EMC
|
CE, FCC
|
|
EMI
|
EN 55022 Class B, EN 61000-3-2, EN 61000-3-3, FCC Part 15 Subpart B Class B
|
|
EMS
|
EN 55024, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC-61000-4-6, IEC 61000-4-8, IEC-61000-4-11
|
|
Green Product
|
RoHS, CRoHS, WEEE
|
|
• Power Requirements
|
|
Power Consumption
|
UPort 1110: 30 mA @ 5 VDC
UPort 1130: 60 mA @ 5 VDC
UPort 1130I: 65 mA @ 5 VDC
UPort 1150: 77 mA @ 5 VDC
|
|
• MTBF (mean time between failures)
|
|
Time
|
1,949,025 hrs
|
|
Database
|
Telcordia (Bellcore), GB
|
|
• Warranty
|
|
Warranty Period
|
5 years
|
|
|
|
 |
|
 |
|
|
|
 |
|
 |
|
Features
- Compatible with USB 2.0
- 12 Mbps USB data rate
- Software selectable RS-232, RS-422, 4-wire RS-485, and 2-wire RS-485
- Certified drivers provided for Windows (including Vista), WinCE 5.0, and Linux
- 15 KV ESD protection for all serial ports
- 2 KV optical isolation protection (UPort™ 1150I)
- Full modem status LEDs for UPort™ 1150I
|
|
|
|
|
|
|
